Item | CDM/F1 | CDM/F2 | CDM/F3 | CDM/F4 | CDM/F5 | CDM/F8 | CDM/F10 | CDM/F12 | CDM/F15 | CDM/F20 |
Rated Flow [m³/h] | 1 | 2 | 3 | 4 | 5 | 8 | 10 | 12 | 15 | 20 |
Rated Flow [l/s] | 0.28 | 0.56 | 0.83 | 1.1 | 1.39 | 2.2 | 2.78 | 3.3 | 4.17 | 5.6 |
Operating Flow Range [m³/h] | 0.4~2.4 | 1~3.5 | 1.2~4 | 1.5~6 | 2.5~8.5 | 5~12 | 5~13 | 7~16 | 8~23 | 10~28 |
Operating Flow Range [l/s] | 0.11~0.66 | 0.28~0.97 | 0.33~1.1 | 0.42~1.63 | 0.69~2.36 | 1.39~3.3 | 1.39~3.61 | 1.9~4.4 | 2.22~6.39 | 2.8~7.8 |
Max Pressure [bar] | 33 | 33 | 30 | 33 | 32 | 33 | 34 | 32 | 31 | 25 |
Motor Power [kW] | 0.37~3 | 0.37~5.5 | 0.37~5.5 | 0.55~7.5 | 0.37~7.5 | 0.75~15 | 0.75~15 | 1.5~18.5 | 1.1~22 | 1.1~22 |
Temperature Range [℃] | -15~120 | -15~120 | -15~120 | -15~120 | -15~120 | -15~120 | -15~120 | -15~120 | -15~120 | -15~120 |
Max Efficiency [%] | 48 | 52 | 57 | 57 | 66 | 62 | 68 | 63 | 68 | 68 |
CDMF Connection - DIN Flange | DN25 | DN25 | DN25 | DN32 | DN32 | DN40 | DN40 | DN50 | DN50 | DN50 |
CDMF Connection - Thread | R 1¼" | R 1¼" | R 1¼" | R 1¼" | R 1¼" | R 2" | R 2" | R 2" | R 2" | R 2" |
CDMF Connection - Compression Fitting | DN32 | DN32 | DN32 | DN32 | DN32 | DN50 | DN50 | DN50 | DN50 | DN50 |
CDM Connection - DIN Flange | DN25 | DN25 | DN25 | DN32 | DN32 | DN40 | DN40 | DN50 | DN50 | DN50 |
CDM Connection - Oval Flange | Rp1 | Rp1 | Rp1 | Rp1¼ | Rp1¼ | Rp1½ | Rp1½ | Rp1½ | Rp1½ | Rp1½ |
Item | CDM/F25 | CDM/F32 | CDM/F42 | CDM/F65 | CDM/F85 | CDM/F95 | CDM/F125 | CDM/F155 | CDM/F185 | CDM/F215 |
Rated Flow [m³/h] | 25 | 32 | 42 | 65 | 85 | 95 | 125 | 155 | 185 | 215 |
Rated Flow [l/s] | 6.94 | 8.89 | 11.7 | 18 | 24 | 26.39 | 34.72 | 43.06 | 51.39 | 559.72 |
Flow Range [m³/h] | 7.5~32.5 | 16~40 | 25~55 | 30~80 | 50~110 | 45~120 | 60~160 | 75~200 | 90~240 | 110~280 |
Flow Range [l/s] | 2.08~9.03 | 4.4~11.1 | 6.9~15.3 | 8~22 | 13.9~30.6 | 12.5~33.33 | 16.67~44.44 | 20.83~55.56 | 25~66.67 | 30.56~77.78 |
Max Pressure [bar] | 22 | 29 | 30 | 22 | 17 | 24 | 33 | 28 | 40.5 | 35 |
Motor Power [kW] | 2.2~22 | 1.5~30 | 3~45 | 4~45 | 5.5~45 | 5.5~55 | 11~110 | 11~110 | 18.5~200 | 22~200 |
Temperature Range [℃] | -15~120 | |||||||||
Max Efficiency [%] | 73 | 73 | 75 | 76 | 77 | 81.5 | 83 | 82 | 84 | 84 |
Pipe Connection - DIN Flange | DN50 | DN65 | DN80 | DN100 | DN100 | DN100 | DN150 | DN150 | DN200 | DN200 |
